Twin Powder Feeder

Twin Powder Feeder

Our well-proven and dependable gravity wheel feeding system is designed to run quietly and without pulsating. A pulsing-free feed rate of 2g per minute is possible because of the highly precise metering mechanism. The clear sandblasting hopper makes it simple to see how much twin powder feeder is left within. When a low power level is reached, an extra sensor will alert the operator in a timely manner. Calibration of the twin powder feed rate is simple when used in conjunction with the PLC.

Specification for Twin Powder Feeder :

Number of Canisters 2
Canister Capacity 700 CC Each(1400 CC both)
Canister Dimensions (mm) 69mm (Inner Diameter) x 190mm (Height)
Cabinet Dimensions 30” L x 16” B x 23.5” H
Electricity 220V/ 1P/ 50-60 Hz Or 110V/ 1P/ 50-60 Hz
Weight (kg) 65.500 Kg (Approx.)

Powder Feeder MPF700 Twin

MPF 700T Twin Powder Feeder is specifically designed for thermal spray gun coatings. Its small size makes it a portable powder feeder, which can be carried to the site for job work. The unit is controlled to exact and repeatable feed rates. The powder tank (canister) is mounted on a hinged plate which allows users to simply remove excess powder and clean the interior. Separate powder feed and carrier gas controls do it easy to clear excess material throughout the spray system. A remote operation switch can be added to any gun.

Features :

  • Its dual hoppers can be operated and controlled independently of each other, for processing flexibility to feed:
  • A single material using one or both hoppers
  • Two different materials simultaneously
  • Two different materials for a layered or bond coat/topcoat system
  • Designed for non-stop continuous operation of the same or different powders.
  • Feed rate can be simply varied from 1 RPM up to 29 RPM.
  • It has a digital display that ensures correct readings.
  • Remote or Local twin powder feeder control selectable.
  • Sensor less vector control technique for accurate RPM control.
  • It is compatible with a wide range of thermal equipment such as Plasma, HVOF System and Combustion Powder Flame spray systems.
  • This unit is provided with a powder pressure gauge to regulate the pressure accurately.
  • Safety Valve is provided to release high canister pressure when required.

Specification for MPF700 Twin :

Number of Canisters 2
Canister Capacity 3350 CC Each
Cabinet Dimensions 33” L x 16.5” B x 27” H
Electricity 220V/ 1P/ 50-60 Hz Or 110V/ 1P/ 50-60 Hz
Weight 84 Kg (Approx.)
Canister Dimensions 120mm (Inner Dia.) x 310mm (Height)

MPF 3350 Twin Powder Feeder is specifically designed for thermal spray coatings. Its compact size makes it a portable powder feeder, which can be carried to the site for job work. The unit is controlled to exact and repeatable feed rates. The powder container (canister) is mounted on a hinged plate which allows users to simply remove excess powder and clean the interior. Separate powder feed and carrier gas controls make it easy to clear excess material throughout the thermal spray booth. A remote operation switch can be added to any gun.

Features

  • Feed rate can be simply varied from 1 RPM up to 29 RPM.
  • Large canister capacity.
  • Low wear and maintenance requirements.
  • It has a digital display which ensures correct readings
  • Remote or Local powder feed control selectable.
  • Sensorless vector control technique for accurate RPM control.
  • It is compatible with a wide range of thermal equipment such as Plasma, HVOF systems, and Combustion Powder flame spray systems.
  • This unit is provided with a powder pressure gauge to regulate the pressure accurately.
  • Safety Valve is provided to release high canister pressure when required.

Powder Feeder MPF 3350 Twin Manufacturers in India

We are one of the best Powder Feeder MPF 3350 Twin manufacturers in India and we also provide Sand Blasting Machine, Portable Shot Blasting machine, Grit blasting machine, thermal spray gun, metalizing guns, Shot Blasting Machine in India at a low price for sale. we are the best portfolio of thermal spray guns with the best price etc Jodhpur, Rajasthan, India with the best quality.
